Wetting and Dispersing Additive for Carbon Black and Transparent Red Pigment

Kabasph^®KBS-6173 is a solvent-based general-purpose polymer dispersant. Its core advantages lie in its excellent dispersion and color development performance for carbon black and organic pigments (especially transparent red), as well as its strong adhesion in baking coatings, heavy-duty anti-corrosion systems, and similar applications. It is widely used in industrial coatings, automotive coatings, anti-corrosion coatings, printing inks, and other related fields.

Chemical Name :
Solution of block copolymerized compounds with pigment affinity groups
Application :
Industrial coatings, Automotive coatings, Anti-corrosion coatings, Wood coatings, Architectural coatings, Printing inks, Pigment concentrates, etc
Product model :
KBS-6173
Viscosity :
50-500 cps at 25℃
Appearance :
Yellow to brownish-yellow liquid
brand :
Kabasph

Inquiry now

product introduction

In ink-related tests, KBS-6173 dispesing Additive demonstrates strong dispersing performance for carbon black. When dispersing pigment carbon black C311 in an alkyd resin (Sanmu 3880) cyclohexanone solvent system, the color paste prepared with KBS-6173 shows an initial fineness of 10 μm, good flowability, and remains stable in fineness without sedimentation after storage at 60°C for 7 days. In saturated polyester resin systems for dispersing medium- to high-pigment carbon black, our KBS-6173 is also one of the recommended options.

KBS-6173 is specifically recommended for use in the printing ink industry and is comparable to BYK-171 and BYK-2163. In solvent-based heavy-duty anti-corrosion coatings (such as epoxy and polyurethane systems), KBS-6173 is recommended as an alternative to EFKA 4063.

Product Data:

Appearance	Transparent yellow liquid
Odour	Slight
Acid value (mg KOH/g)	1-15
Amine value (mg KOH/g)	1-15
Density (g/cm³ at 23℃)	0.90-1.20
Viscosity (cps at 25℃)	50-500
Active ingredient (%)	45
Boiling point(℃)	＞144
Flash Point(℃)	＞60
Solvent	N-Methyl-2-pyrrolidone (NMP); Dibasic Ester (DBE); Propylene Glycol Monomethyl Ether Acetate (PMA)

Key Features and Performance Advantages of Kabasph® KBS-6173

Excellent carbon black dispersion and color development: In black coatings based on various resin systems such as polyester and epoxy 128, 6173 demonstrates outstanding viscosity reduction and superior color development with high blackness ratings. When dispersing Transparent Red 3BL in a 965 resin system, its transparency is superior to that of EFKA 4310.
Excellent viscosity reduction: In tests on solvent-based industrial coatings (comparable to certain ink systems), KBS-6173 demonstrates outstanding viscosity reduction performance in black coatings based on various resin systems such as polyester and epoxy 128, comparable to BYK-163.
Enhanced coating performance: Although primarily derived from coating test data, it demonstrates excellent adhesion in baking systems (no clearcoat was lifted during tape pull tests). This property may also be an added advantage in ink applications requiring strong adhesion, such as certain specialty inks.
Good anti-settling performance: In overprint coatings based on polyester systems, KBS-6173 demonstrates good anti-settling properties.

Typical Applications

Industrial coatings
Automotive coatings
Anti-corrosion coatings
Wood coatings
Architectural coatings
Printing inks
Pigment concentrates

Application

Packaging and Storage

25kg iron drum with inner coating or 180kg ring plastic drum

Keep the container tightly closed and store in a cool, dry and ventilated place.

Keep container tightly closed after use and store upright to prevent leakage.
