Functional resin

Automotive Coating Grade Aldehyde Resin SH-98S

SH-98S, developed and manufactured by China AAB Industry Group, is a colorless to pale yellow aldehyde resin widely used in automotive coatings. Due to its exceptional compatibility, excellent optical properties, physical and chemical stability, SH-98S is an ideal choice for automotive coatings and inks. It not only enhances coating performance but also optimizes color paste processing, providing long-lasting color brilliance and durability for both the exterior and interior of automobiles.

  • Chemical Name :

    Aldehyde Resin
  • Application :

    General industrial paints and coatings, Repair industrial paints and coatings, Wood Coatings, Inks, Adhesives and Specialty Coatings and so on
  • Product model :

    SH-98S
  • Appearance :

    a colorless to pale yellow transparent solid

SH-98S (CAS No. 28931-47-7, Chemical Formula C6H14N2O3) is insoluble in water but soluble in most organic solvents. Its excellent compatibility and solubility allow it to effectively enhance the gloss, adhesion, hardness, and yellowing resistance of coating films. Owing to its favorable pigment and filler wetting properties, along with low dissolution and melt viscosity, it serves as a superior universal grinding resin for color pastes. When used in coatings, it also helps increase the solids content of the formulation.



Properties:

Project

Parameter

Test method

Appearance

Colourless or slightly yellow transparent solid powder or granules

by visual inspection

Softening point(°C)

90-100

ISO4625-1:2004

Gardner color

<1

ISO4630-1:2004

Acidity value (mgKOH/g)

<3

ISO2114:2000

Hydroxyl value(mgKOH/g)

45-75

DIN53240-2:1998

Motion viscosity (mm2/s)

≥15

GB/T 1660-2008

Density (g/cm3)

1. 10±0.05

ISO1183-1:2004(E)B



The solution of resin was 50% by mass, the solvent was 85% by mass butyl acetate and 15% by mass anhydrous ethanol

The resin was dissolved into 50% anhydrous ethanol solution and the viscosity was measured at 20°C





Key Features of SH-98S Aldehyde Resin:

  • Excellent compatibility with diverse resin and solvent systems
  • Outstanding resistance to yellowing for long-term color clarity
  • Superior pigment wetting and dispersion efficiency
  • Enhances gloss, adhesion, hardness, and film build



AAB Group SH-98S Aldehyde Resin Automotive Application

  • Automotive Coatings

Automotive OEM paints, refinish coatings, and plastic part coatings

  • Color Grinding Pastes

Serving as a universal grinding resin for color pastes, SH-98S enables uniform pigment dispersion and precise color control, making it suitable for customized vehicle colors and high-performance decorative coatings.

  • Interior and Composite Coatings

SH-98S improves adhesion, gloss, and wear resistance of coatings applied on plastic and composite substrates, enhancing the quality, appearance, and service life of automotive interior components.



Aldehyde resin



Packaging and Storage:

25kg/bag, customizable according to requirements.

Store in a dry and dark place below 30℃, and seal after use.

Shelf life: 2 years
